 MTU 8V 2000 M94
5 cab + 4 crew 		BAUDOUIN M26.3
5 cab + 4 crew		MTU 10V 2000 M94
5 cab + 4 crew		MTU 12V 2000 M96L
5 cab + 4 crew		MTU 10V 2000 M72
5 cab + 4 crew
LOA 37,04 [m] - 121 ft 6 in
LH 36,89 [m] - 121 ft 0 in
LWH 30,66 [m] - 100 ft 7 in
Max beam  8 [m] - 26 ft 2 in
Draft  2,27 [m] - 7 ft 5 in
Unladen displacement 168.000 [kg] - 370,373 [lbs]
Laden displacement 208.000 [kg] - 458,557 [lbs]
Fuel  35.000 [l] - 9,246 [US gal]
Water  4.000 [l] - 1,057 [US gal]
Material GRP
People on board 20
Engine MTU 8V 2000 M94 BAUDOUIN M26.3 MTU 10V 2000 M94 MTU 12V 2000 M96L MTU 10V 2000 M72
Engine HP 1268 1650 1623 1948 1207
Transmission Shaft line
Max speed 16 [kn] 16.5 [kn] 18.5 [kn] 15 [kn]
Cruise speed 12 [kn] 13 [kn] 15 [kn] 12 [kn]
Range 2900 [nm] 2400 [nm] 3000 [nm] 2400 [nm] 3100 [nm]
Cabins 5
Crew Cabins 4
Bathrooms 7
Bathrooms in Crew Qtr 4
Daily Bathrooms 2 Standard
